EN 12385-5
8X19s = 8x(1+9+9) FC/KÖ
Technical Details
|
|
|
|
||
|
Minimum Breaking Load (MBL) |
||||
| kN | ||||
| 1570 | 1770 | 1960 | ||
|
mm |
kg/m |
N/mm2 | N/mm2 | N/mm2 |
|
8.00 |
0.218 |
29.4 |
33.2 |
36.8 |
|
9.00 |
0.275 |
37.3 |
42.0 |
46.5 |
|
10.00 |
0.340 |
46.0 |
51.9 |
57.4 |
|
11.00 |
0.411 |
55.7 |
62.8 |
69.5 |
|
12.00 |
0.490 |
66.2 |
74.7 |
82.7 |
|
13.00 |
0.575 |
77.7 |
87.6 |
97.1 |
|
14.00 |
0.666 |
90.2 |
102 |
113 |
|
15.00 |
0.765 |
104 |
117 |
129 |
|
16.00 |
0.870 |
118 |
133 |
147 |
|
17.00 |
0.983 |
133 |
150 |
166 |
|
18.00 |
1.102 |
149 |
168 |
186 |
|
19.00 |
1.227 |
166 |
187 |
207 |
|
20.00 |
1.360 |
184 |
207 |
230 |
|
21.00 |
1.499 |
203 |
229 |
253 |
|
22.00 |
1.646 |
223 |
251 |
278 |
|
23.00 |
1.799 |
243 |
274 |
304 |
|
24.00 |
1.958 |
265 |
299 |
331 |
|
25.00 |
2.125 |
288 |
324 |
359 |
|
26.00 |
2.298 |
311 |
351 |
388 |
|
27.00 |
2.479 |
335 |
378 |
419 |
|
28.00 |
2.666 |
361 |
407 |
450 |
|
29.00 |
2.859 |
387 |
436 |
483 |
|
30.00 |
3.060 |
414 |
467 |
517 |
|
31.00 |
3.267 |
442 |
498 |
552 |
|
32.00 |
3.482 |
471 |
531 |
588 |
|
33.00 |
3.703 |
501 |
565 |
625 |
|
34.00 |
3.930 |
532 |
600 |
664 |
|
35.00 |
4.165 |
564 |
635 |
703 |
|
36.00 |
4.406 |
596 |
672 |
744 |
|
37.00 |
4.655 |
630 |
710 |
786 |
|
38.00 |
4.910 |
664 |
749 |
829 |
|
39.00 |
5.171 |
700 |
789 |
873 |
|
40.00 |
5.440 |
736 |
830 |
919 |
|
41.00 |
5.715 |
773 |
872 |
965 |
|
42.00 |
5.998 |
811 |
915 |
1013 |
|
43.00 |
6.287 |
851 |
959 |
1062 |
|
44.00 |
6.582 |
891 |
1004 |
1112 |
|
45.00 |
6.885 |
932 |
1050 |
1163 |
|
46.00 |
7.194 |
973 |
1097 |
1215 |
