EN 12385-5
8X19s = 8x(1+9+9) IWRC/ÇÖ
Technical Details
|
Rope dia. |
Unit Weight |
|
||
|
Minimum Breaking Load (MBL) |
||||
|
kN |
||||
|
1570 |
1770 |
1960 |
||
|
mm |
kg/m |
N/mm2 |
N/mm2 |
N/mm2 |
|
8.00 |
0.260 |
35.8 |
40.3 |
44.7 |
|
9.00 |
0.330 |
45.3 |
51.0 |
56.5 |
|
10.00 |
0.407 |
55.9 |
63.0 |
69.8 |
|
11.00 |
0.492 |
67.6 |
76.2 |
84.4 |
|
12.00 |
0.586 |
80.5 |
90.7 |
100.5 |
|
13.00 |
0.688 |
94.5 |
106 |
118 |
|
14.00 |
0.798 |
110 |
124 |
137 |
|
15.00 |
0.916 |
126 |
142 |
157 |
|
16.00 |
1.042 |
143 |
161 |
179 |
|
17.00 |
1.176 |
162 |
182 |
202 |
|
18.00 |
1.319 |
181 |
204 |
226 |
|
19.00 |
1.469 |
202 |
227 |
252 |
|
20.00 |
1.628 |
224 |
252 |
279 |
|
21.00 |
1.795 |
246 |
278 |
308 |
|
22.00 |
1.970 |
271 |
305 |
338 |
|
23.00 |
2.153 |
296 |
333 |
369 |
|
24.00 |
2.344 |
322 |
363 |
402 |
|
25.00 |
2.544 |
349 |
394 |
436 |
|
26.00 |
2.751 |
378 |
426 |
472 |
|
27.00 |
2.967 |
407 |
459 |
509 |
|
28.00 |
3.191 |
438 |
494 |
547 |
|
29.00 |
3.423 |
470 |
530 |
587 |
|
30.00 |
3.663 |
503 |
567 |
628 |
|
31.00 |
3.911 |
537 |
606 |
671 |
|
32.00 |
4.168 |
572 |
645 |
715 |
|
33.00 |
4.432 |
609 |
686 |
760 |
|
34.00 |
4.705 |
646 |
728 |
807 |
|
35.00 |
4.986 |
685 |
772 |
855 |
|
36.00 |
5.275 |
724 |
817 |
904 |
|
37.00 |
5.572 |
765 |
863 |
955 |
|
38.00 |
5.877 |
807 |
910 |
1008 |
|
39.00 |
6.190 |
850 |
958 |
1061 |
|
40.00 |
6.512 |
894 |
1008 |
1116 |
|
41.00 |
6.842 |
940 |
1059 |
1173 |
|
42.00 |
7.179 |
986 |
1112 |
1231 |
|
43.00 |
7.525 |
1033 |
1165 |
1290 |
|
44.00 |
7.880 |
1082 |
1220 |
1351 |
|
45.00 |
8.242 |
1132 |
1276 |
1413 |
|
46.00 |
8.612 |
1183 |
1333 |
1476 |
